Specification
Input Voltage: AC90-240V 50-60Hz
Lamp: Phillips 380W Lamp
Control Signal: DMX 512, Master-slave and Sound activated,Auto Run
Control Channel: 18/22 DMX Channels
Power Consumption: 650W
Dimensions: 400x320x645mm
Net Weight: 20.8Kg Gross Weight: 23Kg
Feature
High Brightness Phillips380W Lamp, 1500H Lamp lifespan
540° pan and 270° tilt movement
16 bit smooth and precise resolution for PAN/TILT movement
Scan position memory, auto reposition after unexpected movement
1 Color Wheel with 11 colors + White, linear color conversion and
bidirectional variable speed rotating rainbow effect
1 Rotating Gbo Wheel with 7 gobos + White, variable speed jitter
and bidirectional flow effect
1 Fixed Gobo Wheel with 13 gobos + 2 White, variable speed jitter
and bidirectional flow effect
1 Dynamic Gobo Wheel with 4 fixed gobos and 2 dynamic gobos,
variable speed jitter and bidirectional flow effect
2 independent rotating prisms, 8-facet prism and 6-Facet Prism
Beam: 2°-6° Spot: 8°-60° Wash: 10-65°
Electric frost 、Focus、Shutter
0-100% Linear dimmer adjustment
Pan and Tilt quick locks are convenient for product transportation
and maintenance
IP20 Protection Level, with Rain Cover protection level up to IP44
